Rainscreen Cladding Profiles

View our Cladding Profiles Specifications

AGS Profiles

A range of shaped profiles for easy installation of your rainscreen cladding, for various installation requirements.

Please use the menu aside, to find your ideal Profile shape, thickness and dimensions.

L Shaped Profiles

Aluminium L Profiles

Name	Dimensions A (mm)	Dimensions B (mm)	Thickness (mm)	Max Length (m)
L Profile K1	60 mm	40 mm	2 mm	7 m
L Profile Hangers	60 mm	100 mm	2 mm	7 m
L Profile 01	40 mm	40 mm	2 mm	7m
L Profile 02	50 mm	50 mm	2 mm	7m

Magnelis L-Profiles

Name	Dimensions A (mm)	Dimensions B (mm)	Thickness (mm)	Max Length (m)
L Profile M1	60 mm	40 mm	1.5 mm	7 m
L Profile M2	60 mm	100 mm	1.5 mm	7 m
L Profile M3	40 mm	40 mm	1.5 mm	7 m
L Profile M4	50 mm	50 mm	1.5 mm	7 m
L Profile M5	60 mm	40 mm	2.5 mm	7 m
L Profile M6	60 mm	100 mm	2.5 mm	7 m
L Profile M7	40 mm	40 mm	2.5 mm	7 m
L Profile M8	50 mm	50 mm	2.5 mm	7 m

Name	Dimensions A (mm)	Dimensions B (mm)	Thickness (mm)
L Profile K1	60 mm	40 mm	2 mm
L Progile K2	20 mm	40 mm	2 mm
L Profile Hangers	60 mm	40 mm	2 mm
L Profile 01	40 mm	40 mm	2 mm
L Profile 02	50 mm	50 mm	2 mm

Aluminium T Profiles

Name	Dimensions A (mm)	Dimensions B (mm)	Thickness (mm)	Max length
T Profile T1	60 mm	100 mm	2 mm	7m
T Profile T2	60 mm	40 mm	2 mm	7m
T Profile T3	92 mm	90 mm	2 mm	7m
T Profile 01	50 mm	110 mm	2 mm	7m
T Profile 02	50 mm	120 mm	2 mm	7m
T Profile 03	70 mm	120 mm	2 mm	7m
T Profile 04	50 mm	140 mm	2 mm	7m
T Profile s/Steel insert fire rated 120 minutes	60 mm	100 mm	2 mm	7m

T Shaped Profiles

Magnelis Top Hat Profile

Magnelis Top Hat Elements

Dimensions A (mm)	Dimensions B (mm)	Thickness (mm)	Max Length (m)
25 mm	250 mm	2.5 mm	7 m
25 mm	220 mm	2.5 mm	7 m
25 mm	190 mm	2.5 mm	7 m
25 mm	130 mm	2.5 mm	7 m
30 mm	110 mm	2.5 mm	7 m
30 mm	110 mm	1.5 mm	7 m
30 mm	150 mm	1.5 mm	7 m
30 mm	250 mm	1.5 mm	7 m

Aluminium A-Hanger Brackets

Name	Dimensions A (mm)	Dimensions B (mm)	Length (mm)
Hanger A (optional adjustable screw)	74 mm	20 mm	50 mm
Hanger A (optional adjustable screw)	74 mm	20 mm	70 mm
Hanger A (optional adjustable screw)	74 mm	20 mm	100 mm

Magnelis A-Hanger Brackets

Name	Dimensions A (mm)	Dimensions B (mm)	Length (mm)
Hanger A (optional adjustable screw)	74 mm	20 mm	50 mm
Hanger A (optional adjustable screw)	74 mm	20 mm	70 mm
Hanger A (optional adjustable screw)	74 mm	20 mm	100 mm

A-Hanger Brackets

A-Hanger Profile

A-Hanger Profile Aluminium

Dimensions A (mm)	Dimensions B (mm)	Thickness (mm)	Max Length (m)
74 mm	20 mm	2 mm	7 m

A-Hanger Profile Magnelis

Dimensions A (mm)	Dimensions B (mm)	Thickness (mm)	Max Length (m)
74 mm	20 mm	2 mm	7 m

Z Profiles

Z Profiles Elements

Name	Dimensions A (mm)	Dimensions B (mm)	Thickness (mm)
Profile Z	79 mm	45 mm	1.8 mm

F Profile Elements

Name	Dimensions A (mm)	Dimensions B (mm)	Thickness (mm)
Profile F	50 mm	40 mm	1.8 mm

F Profiles

U Profiles

U Profile Elements

Name	Dimensions A (mm)	Dimensions B (mm)	Thickness (mm)
Profile F	36 mm	39 mm	1.8 mm
